INDUSI based ATP protection systems consists of central device, locomotive and track balises as well as signal and operating elements located in the locomotive’s cabin. As a safety system, ATP system should be carefully installed and maintained in proper working condition by regular and specific testing of its central and peripheral units.
ASI - testing device for the central unit of INDUSI I60 (ALTPRO, Siemens, SEL) based ATP system. It can simulate all actual working conditions in order to test them. There is a possibility to test with external or internal (integrated) locomotive balise.
LMI18 – testing device for locomotive balises. It is used for functional testing of ALTPRO, Siemens and SEL INDUSI locomotive balises used as a part of any INDUSI ATP system.
PMI3 – testing device for track balises. It can test track balises made by any producer worldwide. It offers contactless frequency measuring and storing the information directly to the internal memory of the device. Long-life accumulator battery enables daylong (up to 12 hours) outdoor measuring.
ASIL – testing device for locomotive electrical installations. It is possible to test all lines and voltage levels of particular signals before deinstallation of the ATP central unit. It simulates signals from the speed measuring and recording devices.
IR-I 15 – testing device for incident recorder testing. The operator can easily configure parameters such as: digital and analog inputs and outputs, continuous monitoring of all system states, simulation of train movement, simulation of failure state of incident recorder.
